GoldMatt® Brush Finish

Infinite possibilities in aluminum finishing solutions

GoldMatt® Brush Finish

Description

Many designers admire the deep rich color and textures of brass, and it’s an alloy that offers many other appealing properties. But those same aesthetic looks can be obtained using GoldMatt ® Brush SL [Short Line] which is the solution. Along with the rich gold-brass appearance it provides the engineer with reduced weight (60% less than brass). That means more metal for your money, and lowering inventory and freight costs. And to top it off, GoldMatt ® Brush SL [Short Line] material is UV stable.

Applications

  • Gas Station Companies
  • Heaters
  • Signage
  • Store Fronts
  • Backsplashes
  • Wall Panels
  • Window Mutton Bars

Aluminum Properties

  • Alloy: 5205 [Same as 5005]
  • Temper: H18, H34
  • Finish: Short Line Brush

Mechanical Properties

  • Temper: H18
  • UTS: 27 ksi min [186MPa]
  • YTS: Not Applicable
  • Elongation: 1% min
  • T Bend: 3t min
  • Temper: H34
  • UTS: 20-26 ksi [138-179 MPa]
  • YTS: 15 min [103 MPa]
  • Elongation: 3% min
  • T Bend: 1t min

Anodize Film Thickness

  • Standard Film:
  • 0.250 mil Nominal *6.4 μm+

Anodize Finish Properties

  • Optical: Not Applicable
  • Gloss: Medium Matte
  • Color : D092, Medium Gold
  • Color Target: Delta E ≤ 5
  • UV Stable: Yes
  • Seal: S3, Duplex Seal III
  • Quality Grade: 2
  • Other: None

Chemical Properties

  • Si: 0.30 %
  • Fe: 0.70 %
  • Cu: 0.20 %
  • Mn: 0.20 %
  • Mg: 0.50—1.10 %
  • Cr: 0.10 %
  • Zn: 0.25 %
  • Other: 0.15 %
  • Al: Remainder

Industry Standards

GoldMatt® Brush meets RoHS Compliant and ISO 9001 standards.

Sustainability and LEED (Leadership in Energy and Environmental Design)

  • Recycled Content:
  • 100% recyclable
  • Post-Consumer Content = 1.6%
  • Post-Industrial Content = 12.9%
  • Volatile Organic Compounds:
  • Anodized aluminum does not contain any VOC’s.
