CLEARCUT SINGLE FLUTE ROUTER

We aim to provide you with the right tool at the right time for your routing needs.

CLEARCUT SINGLE FLUTE ROUTER

CLEARCUT

Long Series Single Flute Router for Aluminium & Plastics

Description



Solid carbide single flute, upward spiral, 15° helix. Manufactured from Micrograin Carbide, to extremely tight tolerances with a highly polished flute.


Application



Designed to give an exceptional finish on perspex and acrylic materials. In some cases eliminating the need for flame polishing components after cutting. For best results on acrylics use on a well maintained machine, cut anti-clockwise and use ITC Minimal-Amount-Lubricant. This range of tool also offers exceptional surface finish on foamex and similar materials.

Metric Sizes

Catalogue No
Size
Shank Diameter
Overall Lenght
Lenght of Cut
180-1181-10-C
3
3
40
8
180-1181-10-D
3
3
40
12
180-1181-10-E
3
3
40
6
180-1575-10-C
4
4
40
11
180-1575-10-D
4
4
50
15
180-1575-10-E
4
4
50
6
180-1969-10-C
5
5
50
12
180-1969-10-D
5
5
58
21
180-2362-10-C
6
6
58
21
180-2362-10-D
6
6
75
26
180-2362-10-E
6
6
58
14
